Product Details:
Payment & Shipping Terms:
|
Model: | SFM3642E Cold Pipe Cutter And Beveler | Drive Mode: | Electric |
---|---|---|---|
Finish: | Anodizing Sand Blasting | Function: | Cut, Bevel, Counterbore, Drill And Mill Pipes |
Application: | Nuclear Power, Thermal Power, Chemical Plant, Natural Gas, Boiler Plant, Pharmaceutical Factory | Tool Slide: | Spring,thick-wall,drilling&beveling Tool Slides |
Highlight: | cold pipe cutting and bevelling machine,pipe cutter and beveler |
High Strength Cold Pipe Cutter And Beveler Anodizing Sand Blasting Finish
Cold Pipe Cutter And Beveler Introduction
SFM series are portable processing equipment for cutting, beveling and end prefabrication of various pipes,
with which cutting and beveling can be conducted at the same time.
Cold Pipe Cutter And Beveler Application
■ Oil and gas field
■ Chemical plant
■ Boiler plant
■ Nuclear power & thermal power
■ Pharmaceutical factory
■ Ship building and repaire
Cold Pipe Cutter And Beveler Features
■ Split frame structure, can be quickly install
■ Cold Cutting and Beveling, no heat affected zones
■ Aeronautical aluminum material ensure portability
■ Low axial and radial clearance
■ Full closed bearing and driving gear system for operation safety
■ Machining OD of pipe from 2” up to 84”
Cold Pipe Cutter And Beveler Specification
■ Drive Options: Pneumatic, Hydraulic, and Electric
■ Air requirements: 2-3m³/min
■ Hydraulic requirements: 65L/min,10MPa (15.8GPM,1500PSI)
■ Electric requirements: 220V/AC 50/60Hz
■ Feed mode: Star wheel, automatically
■ Feed rate: Fixed@0.08mm per circle
■ Used for pipe material: carbon steel, alloy steel, stainless steel, duples stainless steel, nickel alloy
Beveling type
Manufacture
Working On Site
