Customized Tools Hydraulic Pipe Cutting And Beveling Machine Processing Various Pipes

Customized Tools Hydraulic Pipe Cutting And Beveling Machine Processing Various Pipes
Customized Tools Hydraulic Pipe Cutting And Beveling Machine Processing Various Pipes Customized Tools Hydraulic Pipe Cutting And Beveling Machine Processing Various Pipes

Large Image :  Customized Tools Hydraulic Pipe Cutting And Beveling Machine Processing Various Pipes

Product Details:
Place of Origin: Jiangsu, China
Brand Name: BHY
Certification: ISO 9001:2008, CE, CU-TR, ISO14001:2004,OHSAS 18001:2007
Model Number: SFM206H
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiate
Packaging Details: Aluminum case, wooden case or metal packing case
Delivery Time: 30-45 work days
Payment Terms: L/C, T/T,
Supply Ability: 1000 sets/year
Detailed Product Description
Model: SFM206H Drive Mode: Hydraulic
Dimension: 910*810*330mm Feed Method: Star Wheel System
Finish: Anodizing Sand Blasting Brand: Bohyar
High Light:

split frame pipe cutting machine

,

cold cutting pipe equipment

Split Frame Machine



Product Introduction

SFM series machines are available to cut, bevel, counterbore, drill and mill pipes from 2 inch - 84 inch O.D. (50-2133.6mm) on all diameter of carbon steel, stainless steel, and various types of alloy pipes. They are widely used in nuclear power, thermal power, petroleum, chemical plant, natural gas, boiler plant, pharmaceutical factory and other areas.



Specifications

We have three drive modes and they also have different technical parameters. The air requirements are 2-3m³/min. The hydraulic requirements are 65L/min, 10mpa. The electric requirements are 220V/AC. We adopt the star wheel system with 0.08mm/r feed amount. The finish is anodizing sand blasting. We have different packaging methods such as aluminum alloy, metal packing case or wooden box according to the different models of split frame machines.



Product Features

■ Multi-point pipe clamping system which can securely clamp the equipment onto the pipeline
■ Feed system offers low clearance operation with precise feed.
■ Low friction adjustable bearing system provides maximum stability and extended machine life
■ Full closed bearing and driving gear system for operational safety
■ Adjustable Bearing System-Distributes load evenly to ensure stability
■ Interchangeability of Components-Allows accessories & tool slides to mount to multiple ring sizes



Tool Slides

Spring tool slide It is used to track the surface of out-of-round pipes, which can greatly save installation, adjustment and cutting time. It can quickly and automatically track the system to ensure even feed, and can keep standard wall thickness of large diameter counterbore when combined with counterbore tool slide.

Thick-wall tool slide



It can be applied to SFM 0206 to 4248 with stroke of 64 mm;

It can be used in large-size pipes and pipes with different wall thicknesses.

Drilling and milling tool slide

Achieve pipe cutting by using the drilling and milling.

High-strength tool slide, smooth cutting and simple operation.

Internal boring tool slide It is suitable for pipeline internal boring.
Bridge type tool slide It is suitable for pipeline internal boring and single point beveling.



FAQ

Q: Are you a manufacturer?

A: yes, of course. We are a Chinese manufacturer with own factory and team to manufacture the split frame machines.

Q: What’s your main business?

A: we are mainly engaged in the manufacturing pipe cutting and beveling machines. We also offer on-site machining services and valve repairement service.

Q: What is your enterprise culture?

A: we pay attention to the enterprise culture and our culture is healthy life and happy work.
