60inch - 72inch Cold Pipe Cutting And Bevelling Machine Hydraulic driver Out Mounted
Portable Pipe Cutting And Beveling Machine Introduction
Each pipe cutting beveling machine within the Hydraulic series of clamshells is engineered to operate safely and accurately even in the most demanding environments and critical applications. The rugged fixed base, steel pinion gear and high bearing count within each machine result in a rugged combination ready to perform when called upon.
Portable Pipe Cutting And Beveling Machine Features
■ Multi-point pipe clamping system which can securely clamp the equipment onto the pipeline
■ Feed system offers low clearance operation with precise feed.
■ Low friction adjustable bearing system provides maximum stability and extended machine life
■ Full closed bearing and driving gear system for operational safety
■ Adjustable Bearing System-Distributes load evenly to ensure stability
■ Interchangeability of Components-Allows accessories & tool slides to mount to multiple ring sizes
Portable Pipe Cutting And Beveling Machine Dimension
The axial and radial clearance tables of installing thick-wall tool slide and hydraulic motors |
|||||||
Model |
A(mm) |
B(mm) |
C(mm) |
D (mm) |
E (mm) |
F (mm) |
G (mm) |
SFM0206 |
176 |
70 |
122 |
176 |
225 |
253 |
164 |
SFM0408 |
228 |
70 |
122 |
176 |
225 |
253 |
164 |
SFM0612 |
332 |
70 |
122 |
176 |
225 |
253 |
164 |
SFM0814 |
364 |
70 |
122 |
176 |
225 |
253 |
164 |
SFM1016 |
416 |
70 |
122 |
176 |
225 |
253 |
164 |
SFM1218 |
468 |
70 |
122 |
176 |
225 |
253 |
164 |
SFM1420 |
518 |
70 |
122 |
176 |
225 |
253 |
164 |
SFM1824 |
622 |
102 |
98 |
176 |
235 |
253 |
174 |
SFM2026 |
674 |
102 |
98 |
176 |
235 |
253 |
174 |
SFM2430 |
776 |
102 |
98 |
176 |
235 |
253 |
174 |
SFM2632 |
826 |
102 |
98 |
176 |
235 |
253 |
174 |
SFM3036 |
928 |
102 |
98 |
176 |
235 |
253 |
174 |
SFM3238 |
1006 |
102 |
98 |
176 |
235 |
253 |
174 |
SFM3642 |
1082 |
102 |
98 |
176 |
235 |
253 |
174 |
SFM4248 |
1236 |
102 |
98 |
176 |
235 |
253 |
174 |
SFM3648 |
1296 |
140 |
220 |
276 |
235 |
253 |
174 |
SFM4860 |
1600 |
140 |
220 |
276 |
235 |
253 |
174 |
SFM6072 |
1905 |
140 |
220 |
276 |
235 |
253 |
174 |
SFM7284 |
2210 |
140 |
220 |
276 |
235 |
253 |
174 |
Disassembly
■ Remove the driving device (pneumatic, electric or hydraulic) from the split frame machine;
■ Withdraw the tool slide; disassembly tool slide is not necessarily needed for storage of the machine;
■ Remove foreign matters from the machine such as metal debris and excess cooling agent;
■ Separate the machine into two parts, and check whether there is any metal debris on the bearing guiderail;
■ Drip few drops of rail lubricant on a felt wiper before storing the machine.
Report on Comparison of Product Advantages
Name of component |
Bohyar |
Others |
Advantages |
Fixed coil |
Imported aviation aluminum |
Steel 45# |
Light |
Moving coil |
Die steel |
Steel 45# |
Solid and durable |
Tool |
Imported tool material |
Low price |
Good quality |
Tool slide |
Die steel |
Steel 45# |
Solid and durable |
Tool slide structure |
Compact and small size |
Large |
Small size |
Eccentric shaft |
Quenching and grinding processing |
Lathe processing |
High precision |
Gear |
Gear-grinding processing |
Gear-shaping processing |
High precision, stable operation and low noises |
Power supply (electric) |
Germany motor |
Low price |
Strong power, stable operation, low noise and long service life |
Power supply (pneumatic) |
Taiwan pneumatic motor |
Low price |
Strong power, stable operation, low noise and long service life |
Power supply (hydraulic) |
White motor |
Low price |
Strong power, stable operation, low noise and long service life |
