48in -60in Pipe Cutting And Beveling Machine Processing Various Pipes

48in -60in Pipe (1219.2-1524 mm) Pipe Cutting And Beveling Machine Processing Various Pipes

Portable Pipe Cutting And Beveling Machine Applications:

• Cutting off pipes
• Simultaneous cutting and beveling
• Weld Preparation on the pipe end
• Inside-turning of pipe ends
• Flange facing, or Flange Repairing on-site

Portable Pipe Cutting And Beveling Machine Features

​■ Multi-point pipe clamping system which can securely clamp the equipment onto the pipeline
■ Feed system offers low clearance operation with precise feed.
■ Low friction adjustable bearing system provides maximum stability and extended machine life
■ Full closed bearing and driving gear system for operational safety
■ Adjustable Bearing System-Distributes load evenly to ensure stability
■ Interchangeability of Components-Allows accessories & tool slides to mount to multiple ring sizes

 Portable Pipe Cutting And Beveling Machine Disassembly

■ Remove the driving device (pneumatic, electric or hydraulic) from the split frame machine;

■ Withdraw the tool slide; disassembly tool slide is not necessarily needed for storage of the machine;

■ Remove foreign matters from the machine such as metal debris and excess cooling agent;

■ Separate the machine into two parts, and check whether there is any metal debris on the bearing guiderail;

■ Drip few drops of rail lubricant on a felt wiper before storing the machine.

Storage

■ Clean the dust, debris and accumulated oil or grease on the machine;

■ Inject some lubricating oil to the oil injection hole of the machine, and run the motor for some time to lubricate internal components;

■ Paint or apply a thin layer of anti-corrosion lubricating oil on surfaces that have not be completed or painted;

■ Store the machine in a storage case, and put all components in corresponding compartments;

■ The storage case shall be stored indoors as far as possible and kept dry.
