| Model: | SFM0408H | Drive Mode: | Hydraulic |
|---|---|---|---|
| Net Weight: | 40kg | Package: | Aluminum Alloy, Metal Packing Case Or Wooden Box |
| Certificates: | CU-TR, CE, ISO14001,ISO18001,ISO9001 | Material: | High-strength Aeronautical Aluminum |
| High Light: | split frame pipe cutting machine,split frame machine |
||
SFM series are portable processing equipment for cutting, beveling and end prefabrication of various pipes, with which cutting and beveling can be conducted at the same time. The SFM Series manufactured by Bohyar cuts and bevels the pipe end or middle of pipe by clamping external wall, with processing diameter up to 2100 mm and maximum wall thickness of 100 mm. With an R&D history of nearly one hundred years, the product can process pipes or casings accurately, continuously and vertically.
The SFM Series of Pipe Cutting and Beveling Machines are widely used in long-distance transport pipeline, power plant, nuclear power, petroleum, chemical engineering, natural gas, boiler shop, pharmacy, pipe prefabrication plant, pipeline installation engineering, rush-repair work, etc. Our products play an important role in these fields.
Models
| Model |
Processing range (in) |
Max wall thickness (mm) |
Weight(kg) | Drive mode |
| SFM0206 | 2"~ 6" | 30 | 35 |
Pneumatic Hydraulic Electric |
| SFM0408 | 4"~ 8" | 40 | 40 | |
| SFM0612 | 6"~12" | 80 | 45 | |
| SFM0814 | 8"~14" | 100 | 55 | |
| SFM1218 | 12"~18" | 100 | 70 | |
| SFM1420 | 14"~20" | 100 | 76 |
Electric Hydraulic |
| SFM1824 | 18"~24" | 100 | 123 | |
| SFM2026 | 20"~26" | 100 | 130 | |
| SFM2430 | 24"~30" | 100 | 142 | |
| SFM2632 | 26"~32" | 100 | 150 | |
| SFM3036 | 30"~36" | 100 | 159 | |
| SFM3642 | 36"~42" | 100 | 179 | |
| SFM4248 | 42"~48" | 100 | 198 | |
| SFM4860 | 48"~60" | 100 | 642 | |
| SFM6072 | 60"~72" | 100 | 730 | |
| SFM7284 | 72"~84" | 100 | 820 |
* Processing range can be customized according to the pipe diameter.
The machine delivered will be packed in a portable aluminum alloy suitcase (Medium machine is packed with pushable aluminum case while large-size machine is packed with wooden case or metal packing case). The foam-molded pad will be equipped to prevent shocking of the case, and attached with necessary standard tool, power supply and other accessories. Our company provides all necessary instruments, please refer to the package of product for details.
Warranty information: The split frame machine produced by Bohyar is guaranteed for one year while the motor is six months. In case of any quality problem during the warranty period, we will provide free maintenance and repairment service. And we can provide you with the corresponding product knowledge training. If you need us to go abroad for training, the cost is extra.
Q: Do you have any fixed business partners?
A: We are the certified suppliers by three oil and gas companies affiliated to the government in China-- CNPC, Sinopec, CNOOC. We enjoyed good relationship with them.
Q: How to ensure the quality?
A: All major components are developed on our own production to ensure the quality. We have horizontal machining centers, CNC vertical lathes, vertical machining centers, horizontal CNC lathes, CNC wire cutting machine and other manufacturing equipment and 100,000-class purification plant, and equipped with an experienced manufacturing team.
